主要特性和优势
- 降低信号衰减可产生低开关损耗
- 降低总谐波失真可实现高品质音频切换
- 支持模拟传感器信号多路复用 - 减少ADC的数量
- 控制信号接口至低电压控制器的集成式电平转换
- 低导通电阻和导通电阻平坦度
- 低开关泄漏
- 宽电源电压
- 低输入阈值输入选项
- 过压容限选项
- 高ESD保护，符合IEC61000标准
.jpg)
应用
- 笔记本电脑和PC
- USB端口/集线器、扩展坞和台式机
- 机顶盒
- 高清电视
- VoIP电话
- 打印机
- 光学插座保护
- 限流电路
Featured documents
Latest news and blogs
产品
| 型号 | 描述 | 状态 | 快速访问 |
|---|---|---|---|
| NPS4001 | 5.5 V, 55 mOhm load switch with current limitation | ACT |
|
| NPS4001GV | 5.5 V, 55 mOhm load switch with current limitation | Production | |
| NPS4053 | 5.5 V, 55 mOhm load switch with precision adjustable current limit | ACT |
|
| NPS4053GH | 5.5 V, 55 mOhm load switch with precision adjustable current limit | Production | |
| NPS4053GV | 5.5 V, 55 mOhm load switch with precision adjustable current limit | Production | |
| NPS4053-Q100 | 5.5 V, 55 mOhm load switch with precision adjustable current limit | ACT |
|
| NPS4053GH-Q100 | 5.5 V, 55 mOhm load switch with precision adjustable current limit | Production | |
| NPS4053GV-Q100 | 5.5 V, 55 mOhm load switch with precision adjustable current limit | Production | |
| NPS4069 | 5.5 V, 55 mOhm load switch with current limitation | ACT |
|
| NPS4069GV | 5.5 V, 55 mOhm load switch with current limitation | Production | |
| NPS1000UP | 0.5 V to 1.0 V, 1.5 A peak, 11 mΩ, load switch | Production | |
| NPS1001UP | 0.5 V to 1.8 V, 1.5 A peak, 12 mΩ, load switch | Production |
Visit our documentation center for all documentation
Application note (2) |
|||
|---|---|---|---|
| 文件名称 | 标题 | 类型 | 日期 |
| AN90052.pdf | Nexperia load switch ICs compared to discrete solutions | Application note | 2024-04-09 |
| AN90045.pdf | Nexperia load switch ICs | Application note | 2023-08-08 |
Leaflet (1) |
|||
| 文件名称 | 标题 | 类型 | 日期 |
| nexperia_leaflet_electronics_power_management_load_switch.pdf | NPS4053 load switch leaflet | Leaflet | 2024-03-29 |
Outline 3d (1) |
|||
| 文件名称 | 标题 | 类型 | 日期 |
| sot8044-1_3d.png | HWSON6; SOT8044-1; Plastic thermal enhanced very very thin Small Outline packages, no leads; 6 terminals; 0.65 mm pitch; 2.0 mm x 2.0 mm x 0.75 mm body | Outline 3d | 2022-06-23 |
