恢复整流器

快速恢复、节省空间的器件

我们的200-400 V标准(trr > 500 ns)和快速恢复(trr < 30 ns)整流器可提供功率密度，同时最大程度地减少反向恢复时间和损耗。这些标准和快速恢复的二极管采用我们的汽车级合格铜夹片CFP封装，可提供高电流脉冲能力和高功率密度，兼具高效开关功能，同时能够有效节省空间。

Key features and benefits

  • 1 mm package height for thin PCB designs
  • Up to 60% footprint savings - CFP compared to SMx
  • High current pulse capability due to solid copper clip-bond
  • High efficiency planar technology / High power density
  • Low magnetic inductance optimizes switching behavior
  • 200 V hyper-fast switching parts with optimized recovery time (trr) of < 20 ns
  • High speed switching capability
  • Low voltage drop (VF @ IF(max) ~ 1 V)
  • Low leakage current, also at high temperature
  • AEC-Q101 qualified parts (175 °C Tj (max))

Key applications

  • Polarity protection
  • DC/DC conversion
  • AC/DC conversion
  • Freewheeling of inductive load
  • Standard switching applications
  • High-speed switching applications
  • Engine and Transmission Control Unit
  • Solenoid control
  • Piezo injection

Latest news and blogs

  • 新闻稿
Oct 6, 2022

Nexperia成功增强其CFP功率二极管的范围

Latest videos

Maximize SMPS efficiency with Nexperia’s 200 V PNE recovery rectifier series

Maximize SMPS efficiency with Nexperia’s 200 V PNE recovery ...
Improve accuracy of AOI in PCB production by using modern ...
Improve accuracy of AOI in PCB production by using modern ...

Parametric search

Recovery rectifiers
Please wait loading data...
Parametric search is unavailable.

Products

Type number Description Status Quick access
ES3DP 200 V, 3 A hyperfast PN-rectifier EndOfLife
ES1DVR 200 V, 1 A hyperfast PN-rectifier EndOfLife
ES1DR 200 V, 1 A hyperfast PN-rectifier EndOfLife
ES2DVR 200 V, 2 A hyperfast PN-rectifier EndOfLife
ES2DR 200 V, 2 A hyperfast PN-rectifier EndOfLife
ES2DP 200 V, 2 A hyperfast PN-rectifier EndOfLife
ES1GR 400 V, 1 A hyperfast switching time PN-rectifier EndOfLife
PNE200100CPE 200 V, 2 x 5 A dual common cathode hyperfast recovery rectifier Production
PNU65030EP 650 V, 3 A ultrafast recovery rectifier Production
PNE20050EP 200 V, 5 A hyperfast recovery rectifier Production
PNE20010ER 200 V, 1 A hyperfast recovery rectifier Production
PNE20040EP 200 V, 4 A hyperfast switching recovery rectifier Production
PNE20010EXD 200 V, 1 A hyperfast recovery rectifier Production
PNE20020EP 200 V, 2 A hyperfast recovery rectifier Production
PNE20020ER 200 V, 2 A hyperfast recovery rectifier Production
PNE20040CPE 200 V, 2 x 2 A dual common cathode hyperfast recovery rectifier Production
PNE20080CPE 200 V, 2 x 4 A dual common cathode hyperfast recovery rectifier Production
PNU65010EP 650 V, 1 A ultrafast recovery rectifier Production
PNU65010ER 650 V, 1 A ultrafast  recovery rectifier Production
PNU65020EP 650 V, 2 A ultrafast recovery rectifier Production
PNE20060EPE 200 V, 6 A hyperfast recovery rectifier Production
PNE20030EP 200 V, 3 A hyperfast  recovery rectifier Production
S1DR 200 V, 1 A high power density, standard switching time PN-rectifier EndOfLife
PNE20060CPE 200 V, 2 x 3 A dual common cathode hyperfast recovery rectifier Production
PNE200100EPE 200 V, 10 A hyperfast recovery rectifier Production
PNE20040EPE 200 V, 4 A hyperfast recovery rectifier Production
PNE20080EPE 200 V, 8 A hyperfast recovery rectifier Production
PNE650200EJ 650 V, 20 A hyperfast recovery rectifier Production
PNS40010AER 400 V, 1 A high power density, standard switching time recovery rectifier Production
PNU650100EJ 650 V, 10 A ultrafast recovery rectifier Production
PNU650150EJ 650 V, 15 A ultrafast recovery rectifier Production
PNE20020AER 200 V, 2 A hyperfast recovery rectifier Production
PNE650150EJ 650 V, 15 A hyperfast recovery rectifier Production
PNU650200AEJ 650 V, 20 A ultrafast recovery rectifier Production
PNE650100EJ 650 V, 10 A hyperfast recovery rectifier Production
PNU650200EJ 650 V, 20 A ultrafast recovery rectifier Production
PNE20020EXD 200 V, 2 A hyperfast recovery rectifier Production
PNU650300AEJ 650 V, 30 A ultrafast recovery rectifier Production
PNU650150AEJ 650 V, 15 A ultrafast recovery rectifier Production
PNS40010ER 400 V, 1 A high power density, standard switching time recovery rectifier EndOfLife
PNE20060EPE-Q 200 V, 6 A hyperfast recovery rectifier Production
PNE200100CPE-Q 200 V, 2 x 5 A dual common cathode hyperfast recovery rectifier Production
PNE20040CPE-Q 200 V, 2 x 2 A dual common cathode hyperfast recovery rectifier Production
PNE20040EPE-Q 200 V, 4 A hyperfast recovery rectifier Production
PNE20060CPE-Q 200 V, 2 x 3 A dual common cathode hyperfast recovery rectifier Production
PNE20080EPE-Q 200 V, 8 A hyperfast recovery rectifier Production
PNU65010ER-Q 650 V, 1 A ultrafast recovery rectifier Production
PNE200100EPE-Q 200 V, 10 A hyperfast recovery rectifier Production
PNU65030EP-Q 650 V, 3 A ultrafast recovery rectifier Production
PNE20010EXD-Q 200 V, 1 A hyperfast recovery rectifier Production
PNU65020EP-Q 650 V, 2 A ultrafast recovery rectifier Production
PNU650150AEJ-Q 650 V, 15 A ultrafast recovery rectifier Production
PNE20020EP-Q 200 V, 2 A hyperfast recovery rectifier Production
PNE20040EP-Q 200 V, 4 A hyperfast switching recovery rectifier Production
PNE20030EP-Q 200 V, 3 A hyperfast  recovery rectifier Production
PNE20010ER-Q 200 V, 1 A hyperfast recovery rectifier Production
PNU650300AEJ-Q 650 V, 30 A ultrafast recovery rectifier Production
PNE20020AER-Q 200 V, 2 A hyperfast recovery rectifier Production
PNE20020ER-Q 200 V, 2 A hyperfast recovery rectifier Production
PNU650150EJ-Q 650 V, 15 A ultrafast recovery rectifier Production
PNE20080CPE-Q 200 V, 2 x 4 A dual common cathode hyperfast recovery rectifier Production
PNU650100EJ-Q 650 V, 10 A ultrafast recovery rectifier Production
PNS40010AER-Q 400 V, 1 A high power density, standard switching time recovery rectifier Production
PNE20050EP-Q 200 V, 5 A hyperfast recovery rectifier Production
PNU65010EP-Q 650 V, 1 A ultrafast recovery rectifier Production
PNE650150EJ-Q 650 V, 15 A hyperfast recovery rectifier Production
PNE650100EJ-Q 650 V, 10 A hyperfast recovery rectifier Production
PNE650200EJ-Q 650 V, 20 A hyperfast recovery rectifier Production
PNU650200EJ-Q 650 V, 20 A ultrafast recovery rectifier Production
PNU650200AEJ-Q 650 V, 20 A ultrafast recovery rectifier Production
PNE20020EXD-Q 200 V, 2 A hyperfast recovery rectifier Production
